Trakmat 2440mm x 1130mm Standard Black

Trakmats are excellent medium duty trackway panels, useful for a range of applications. Strong enough to spread the weight of vehicles, grippy enough for pedestrian walking, whilst light enough to be moved by hand, a great all-rounder.

Panel Weight: 35kg
Loading Capacity: 60 Tonnes (Ground Dependant)
Panel Thickness: 12.7mm
Material: High Density Polyethylene (HDPE)
Environment: 100% recyclable

Construction

Parking

Events

Agriculture

Pedestrian

Description

Trakmats are one of the original plastic trackway panels, and still one of the best. Their construction is one of high quality, durable plastic which not only lasts a long time but stands up to endless use and heavy loads. Their size means they are extremely versatile and easy to install, requiring no previous knowledge of trackway or skills. All Weather Access stock both green and black panels, with the green being particularly efficient at reflecting light and not absorbing it, thus avoiding unnecessary damage to the grass beneath.

This product is available for Hiring

Key Features

  • Light enough for one-two man handling
  • Extra hand cut outs for easy offloading from trucks
  • Self-cleaning grip surface
  • Choice of connections
  • Protects against damage to ground and ecologically sensitive sites
  • Available for Hire

Installation (Removal is the opposite procedure)

Manual Handling
Each mat should be lifted by 2 or more people.

Handling
To lift a stack or stillage of mats from a lorry bed use an appropriate forklift truck. Stacks are normally 30-35. Place mat on to the ground to provide the coverage required. Ground preparation is not usually needed.

Connecting Mats
As each mat is placed it is recommended to connect it to the neighbouring mats using the correct connector. To connect 2 mats, place the 2-way connect or underneath the mats. The raised cylinders on the connector unit should fit within the holes on the corner of each mat. When in place secure using 2 connection bolts,(M10 x 25 with steel and rubber washer) taking care not to overtighten. Where 4 mats need to be place together, use the 4-way connector following the same process.

Material: High Density Polyethylene (HDPE)

Panel Size: 2440mm x 1130mm (8×3.7”)

Panel Thickness: 13mm

Panel Weight: 33kg

Loading Capacity: 40 tonnes (ground dependant)

Environmental: 100% recyclable

Very resistant to most chemicals
The material is very inert with a low coefficient of friction
Performs in temperature ranges from below freezing to over 100 degrees fahrenheit
